Vibroflot hydraulique
>
Hydraulic Vibroflot with 150Kw Power and High Compaction Efficiency for Soil Improvement ISO 9001 Certified

Hydraulic Vibroflot with 150Kw Power and High Compaction Efficiency for Soil Improvement ISO 9001 Certified

Nom De Marque: BVEM
Numéro De Modèle: BJVH-350-150
Nombre De Pièces: 1
Prix: 35000 $
Détails De L'emballage: Caisse en bois
Conditions De Paiement: LC, T/T
Informations détaillées
Lieu d'origine:
Chine
Certification:
CE、ISO 9001:2000、ISO 9001:2008
Puissance de vibrateur:
150 kW
Télécommande:
Oui
Poids du vibroflot:
1700 kg
Diamètre extérieur:
350 mm
Vitesse de rotation:
0-2900 tr/min
Compresseur d'air:
20 m3/min
Block d'alimentation électrique:
176 kilowatts
Vibrateur Longueur:
2250 millimètres
Force centrifuge:
214 kN
Journée de conduite:
500-800 millimètres
Garantie:
Soit 1 an, soit 2 000 heures, selon la première éventualité
Capacité d'approvisionnement:
600set/an
Mettre en évidence:

Hydraulic Vibroflot 150Kw power

,

Hydraulic Vibroflot high compaction efficiency

,

Hydraulic Vibroflot ISO 9001 certified

Description du produit
Hydraulic Vibroflot with 150Kw Power and High Compaction Efficiency for Soil Improvement ISO 9001 Certified
Product Overview

With over 50 years of dedication to the vibroflotation industry, BVEM has focused on R&D and investment in vibroflotation products. Our BJVH-350-150 hydraulic vibroflot represents the culmination of technical expertise and innovation, delivering high-efficiency, stable performance for demanding vibroflotation projects.

Working Principle

This hydraulic vibroflot efficiently converts hydraulic energy into mechanical energy (rotational motion) through a hydraulic motor, driving the eccentric block to generate strong horizontal excitation force. Key advantages include:

  • Large output torque for demanding applications
  • Wide speed regulation range with stepless control
  • Excellent impact load resistance
  • Stable power output for consistent performance
Key Features
  • 0-2900rpm stepless speed regulation: Flexible operation matching various construction requirements and soil conditions
  • Wide stratum compatibility: Optimized design provides strong penetration in both soft soil and gravel-containing strata
  • Continuous high-power output: Ensures stable operation and improved project efficiency
  • Water-cooled motor not required: Enables dry method environmental protection construction
  • High adaptability: Compatible with various equipment including pump stations, rotary drilling rigs, excavators, and pile frames
CE Certified ISO 9001 Made in China
Applications

The BVEM Hydraulic Vibroflot (Model: BJVH-350-150) is designed for soil improvement across multiple construction scenarios:

  • Foundation Construction: Compacts soil to ensure stable building foundations
  • Road and Highway Projects: Enhances soil strength and reduces settling for durable infrastructure
  • Retaining Wall Installation: Improves soil stability and prevents erosion
Technical Evolution

BVEM has pioneered advancements in vibroflot technology, including:

  • Transition from electric to hydraulic driving systems
  • Development of both orifice filling and bottom discharge models
  • Expansion of mounting scenarios for diverse construction needs

This equipment provides contractors and engineers with a reliable, high-performance solution for soil improvement projects, combining quality construction with operational efficiency.
